EXWELD sigma3 SC TWISTY
Product Details:
- Operating Temperature Up to 1200C
- Composition Fe, Mn, Si, C, Rutile
- Application General Fabrication, Structural Welding
- Operating Voltage 50-70V AC/DC
- Material Copper Coated Mild Steel
- Diameter 3.15mm
- Flux Content Rutile Type Flux Coated
- Click to View more
X
EXWELD sigma3 SC TWISTY Price And Quantity
EXWELD sigma3 SC TWISTY Product Specifications
- General Fabrication, Structural Welding
- 50-70V AC/DC
- Copper Coated Mild Steel
- Heavy Rutile Coating
- 1400C approx.
- 3.15mm
- Up to 1200C
- Fe, Mn, Si, C, Rutile
- Rutile Type Flux Coated
Product Description
Features:
- WEGENER microprocessor control system for air and extrudate temperature, and to control the motor
- Own air supply in the EC version through a WEGENER brushless Airbox 2,200 W
- Switch between actual and target value display for air heater and extrudate temperature
- Cold start protection (start-up protection dependent on time and temperature)
- Monitoring of the pre-set target temperature of the extrudate heater with motor-stop function if the deviation is too high
- TWISTY: Turnable welding shoe support for flexible change of the welding direction
- Easily exchangeable PTFE welding shoe, adjustable front handle
- The scope of delivery includes a welding shoe of your choice
Range of Application:
Manufacture of reservoirs, tanks and containers, manufacturer of plastic apparatus, pipeline construction, ventilation, automotive, roofing, landfill technology
Materials:
PE, PP, PVDF and other weldable thermoplastic material
| Technical Data | sigma3 SC TWISTY Item no. 30273 |
|---|---|
| Power supply: | 230 V 1/N/PE 50/60 Hz |
| Power consumption: | 3,390 W |
| Air requirement: | self-contained air supply |
| Heating capacity (air): | 2,200 W |
| Welding capacity (PE): | approx. 1.9 kg/h |
| Welding capacity (PP): | approx. 1.8 kg/h |
| Welding rod diameter: | PE: 3, 4, 5 mm / PP: 3, 4 mm |
| Weight: | 5.6 kg |
| Dimensions (L x H x W in mm): | 440 x 230 x 130 |
Exceptional Welding Performance
EXWELD sigma3 SC TWISTY is engineered for optimal arc stability and minimal spatter, ensuring smoother welds and reducing the need for post-weld clean-up. Its rutile-type flux coating delivers excellent slag detachability, making the welding process more efficient for all users.
Versatile Application Range
Designed for both general fabrication and structural welding, this electrode supports a wide variety of industrial and construction projects. Its compatibility with both AC and DC+ power sources offers flexible usage in different environments and on different machinery types.
User-Friendly and Reliable
The electrodes easy slag removal, coupled with a robust tensile strength, simplifies the welding process. Proper storage below 30C prolongs shelf life and maintains performance integrity, ensuring reliability whenever needed for critical tasks.
FAQs of EXWELD sigma3 SC TWISTY:
Q: How should I store EXWELD sigma3 SC TWISTY electrodes to maintain quality?
A: To maintain their performance, store EXWELD sigma3 SC TWISTY electrodes in a dry environment at temperatures below 30C. Proper storage helps prevent moisture absorption and ensures effective welding outcomes.Q: What types of welding applications is this electrode suitable for?
A: EXWELD sigma3 SC TWISTY is ideal for both general fabrication and structural welding, making it versatile for various construction and manufacturing projects that require strong, stable welds.Q: When is it recommended to use this electrode with AC or DC+ polarity?
A: This electrode is compatible with both AC and DC+ polarities, allowing selection according to your welding machine and material requirements. Choose the polarity that matches your projects setup for optimal results.Q: Where can I purchase EXWELD sigma3 SC TWISTY electrodes?
A: You can procure EXWELD sigma3 SC TWISTY through authorized distributors, exporters, manufacturers, service providers, suppliers, and traders across India.Q: What is the recommended voltage and temperature range during operation?
A: Operate this electrode within a voltage range of 50-70V on either AC or DC, and at welding temperatures up to 1200C to ensure optimal melting and joint strength.Q: How does the rutile-type flux coating benefit the welding process?
A: The heavy rutile-type flux coating ensures a stable arc, superb slag detachability, and reduced spatter, which leads to a smoother and cleaner weld with minimal post-process effort.Q: What advantages does the copper-coated mild steel core provide?
A: The copper coating enhances electrical conductivity, reduces corrosion, and extends electrode life, contributing to consistent performance throughout the welding process.Tell us about your requirement
